| Product Name |
PLN-M1108MGB-SF |
| Fixed Port |
08*10/100Base-TX PoE ports (Data/Power) 2*10/100/1000Base-T uplink RJ45 ports (Data) 2*1000M uplink SFP fiber slot ports (Data)(Combo port) 1*Console port (command line ) |
| Ethernet Port |
Port 1-08 support 10/100Base-TX, Port 17-18 support 10/100/1000Base-T auto-sensing, full/half duplex MDI/MDI-X self-adaption |
| Twisted Pair Transmission |
10BASE-T: Cat3,4,5 UTP (≤100 meter) 100BASE-TX: Cat5 or later UTP (≤100 meter) 1000BASE-T: Cat5e or later UTP (≤100 meter) |
| SFP Slot Port |
Gigabit SFP optical fiber interface, default matching optical modules (optional order single-mode / multi-mode, single fiber / dual fiber optical module. LC) |
| Optical Cable |
Multi-mode: 850nm 0 ~ 550M, single-mode: 1310nm0 ~ 40KM, 1550nm0 ~ 120KM |
| Network Protocol |
IEEE802.3 10BASE-T, IEEE802.3i 10Base-T IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T IEEE802.3z 1000Base-X, IEEE802.3x |
| Forwarding Mode |
Store and Forward (Full Wire Speed) |
| Switching Capacity |
64Gbps (non-blocking) |
| Forwarding Rate@64byte |
4.17Mpps |
| MAC |
16K |
| Buffer Memory |
4.1M |
| Jumbo Frame |
9.2K |
| CPU(Hz) |
500M |
| DRAM |
1G |
| Flash |
128M |
| Reset Switch |
Yes, One-button factory reset |
| LED Indicator |
Power: PWR (green), Data: Link, Link/Act (yellow), PoE: PoE(green), Speed: SPD (green |
| PoE Port |
Port 1 to 8 IEEE802.3af/at @ POE |
| PoE Management |
PoE working status Delay start of power supply PoE output priority configuration Scheduling of PoE operation and time |
| Power Supply Pin |
Default :1/2 (+), 3/6 (-), optional:4/5 (+), 7/8 (-) |
| Max Power Per Port |
30W; IEEE802.3af/at |
| Total PWR / Input Voltage |
250W/ (AC100-240V |
| Power Consumption |
Standby <6W Full load <250W |
| Power Supply |
Built in power supply, AC100~240V50-60Hz 5.0A |
| Operation TEMP / Humidity |
-20~+55°C;5%~90% RH Non condensing |
| Storage TEMP / Humidity |
-40~+75°C;5%~95% RH Non condensing |
| Dimension (L*W*H) |
270*181*44.5mm |
| Net /Gross Weight |
<3.5kg |
| Installation |
Desktop, wall mounted,19-inch 1U cabinet installation |
| Lightning protection / protection level |
Port lightning protection: 4KV 8/20us, Protection level: IP30 |
| Certification |
CCC; CE mark, commercial; CE/LVD EN60950; FCC Part 15 Class B; RoHS |
| Interface |
IEEE802.3X (Full-duplex) Broadcast storm control based on port speed The speed limit of the message flow in the access port. The minimum particle size is 64Kbps. |
| VLAN |
Q In Q configuration VLAN based on protocol 4K VLAN based on port, IEEE802.1q |
| Port Aggregation |
LACP, Static aggregation Max 8 aggregation groups and 8 ports per group. |
| Spanning Tree |
STP (IEEE802.1d), RSTP (IEEE802.1w), MSTP (IEEE802.1s) |
| Multicast |
MLD Snooping v1/v2, Multicast VLAN IGMP Snoopingv1/v2/v3, Max 64 multicast groups, Fast log out |
| Image |
Bi-directional traffic mirroring supporting the basic port |
| QoS |
8*Output queues of each port 802.1p/DSCP priority mapping Diff-Serv QoS, Priority Mark/Remark Queue Scheduling Algorithm (SP, WRR, SP+WRR) |
| ACL |
Port-based Issuing ACL L2 to L4 packet filtering, matching first 80 bytes message. Provide ACL based on MAC, Destination MAC address, IP Source, Destination IP, IP Protocol Type, TCP/UDP Port, TCP/UDP Port Range, and VLAN, etc. |
| Security |
Port isolation, Storm control. IP-MAC-VLAN-Port binding |
| DHCP |
DHCP Client, DHCP Snooping, DHCP Relay |
| Management |
NTP SNMP V1/V2C/V3 One-key recovery System work log Web Management (HTTPS) |
