| Model |
PLC-5832H2/PM-4K |
| System |
Embedded Linux |
| Video Network Input |
32 CH IPC input (16CH after enabling AI) |
| Network Input Resolution |
8MP/6MP/5MP/4MP/HDMI × 1: 3840×2160@60fps/3840×2160@30fps/1920×1080/1280×1024 VGA × 1: 1920×1080/1280×1024/1024×768/1080P/1280×1024/960P/720P/960H/D1/CIF |
| Video Output |
HDMI × 1: 3840×2160@60fps/3840×2160@30fps/1920×1080/1280×1024 VGA × 1: 1920×1080/1280×1024/1024×768 |
| Compression |
H.265S / H.265+ /H.265 /H.264 |
| Multi-screen Display |
1/4/6/8/9/13/16/25/32/36 |
| Audio Network Input |
32 channel IPC audio input |
| 2-way Audio |
RCA × 1 |
| Local Output |
RCA × 1 |
| Compression |
G.711(U/A) |
| Decoding Capability |
1CH 8MP/ 4CH 1080P |
| Record Stream |
Dual stream recording |
| Resolution |
8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF |
| Frame Rate |
PAL: 25fps |
| Simultaneous Playback |
Max. 16 channel |
| Play Back Search |
Time slice / time / event / tag /smart search |
| Play Back Smart Search |
Highlighted colour to display the camera record in a certain period of time, different colours refer to different record events |
| Play Back Function |
Play, pause, FF, FB, digital zoom, etc. |
| Live View/ Playback |
1 Channel 6MP; 4CH 720P |
| Mode |
Manual, sensor, motion, exception, smart events |
| Input |
Support IPC alarm input |
| Output |
Support IPC alarm output |
| Triggering |
Record, snapshot, buzzer, pre-set, e-mail, etc. |
| Face Channel |
16 CH |
| Face Picture Database |
32 libraries 5000 Face Pictures |
| Computing Capability |
180 pictures / minute |
| Face Picture Search |
Search by picture is supported |
| Database Management |
Add, modify, delete and search face pictures |
| Face Picture Adding |
Add face pictures through APP, WEB and external import |
| External face picture enrolment |
Resolution：128 x 128 ～ 1920 x 1080 Size：≤ 70KB Format: jpg & jpeg |
| Face Picture Comparison |
Supports allow list and block list alarm |
| Face Track |
Yes |
| Map of Face Track |
Resolution： 2560 x 1920 Size：≤ 512KB Format: jpg & jpeg |
| Statistic Graph of Face Information |
Bar graph, pie chart |
| Statistic Mode of Face Information |
Statistics by day, week, month, quarter as well as customized time period |
| Interface |
RJ45 1000 Mbps × 1 |
| Network Protocol |
TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, 802.1x, ONVIF, etc. |
| Incoming Bandwidth |
200Mbps |
| Outgoing Bandwidth |
200Mbps |
| Client Connection |
Max. 20 users’ access |
| Plate Recognition |
Yes |
| Mobile Device |
iOS, Android |
| Storage |
SATA × 2, max 10T per HDD |
| Local Backup |
U disk, USB mobile HDD |
| Network Backup |
Yes |
| USB |
USB 2.0 × 2 |
| Remote Controller |
Optional |
| RS 485 |
Yes (full-duplex), connect to PTZ or keyboard |
| Power Supply |
DC12V/4A |
| Consumption |
≤ 10W (without HDD) |
| Dimensions (mm) |
380 × 268 × 45 (W × D × H) |
| Working Environment |
10 ～ 50°C, 10% ～ 90% humidity |
| Certificate |
CE, FCC |
| Environmental Protection |
Complies with Directive EU RoHS, REACH and WEEE |
