| Model No. |
PLC-422M-MZ-AU-IR5 PR |
| Imaging Device |
1/2.7" |
| Effective Pixels |
2MP 1920(H)×1080(V) |
| Scanning System |
Progressive CMOS |
| Min. Illumination |
Color 0.006lux @ F1.6(AGC ON) ; B/W 0 lux @ IR ON |
| Focal Length (Zoom Ratio) |
2.8-12mm |
| Max. Aperture Ratio |
F No. 1.8(W) ~ 3.3(T) |
| Angular Field of View |
H:107°（W）-35°（T）V:54°（W）-20°（T）D:133°（W）-40°（T） |
| Min. Object Distance |
1.2m（W/T） |
| Lens Type |
Motorized(Ø14) |
| IR Viewable Length |
Up to 50m |
| Camera Title |
On/Off |
| Day & Night |
IR cut filter with auto switch Day/Night/Auto/Image/Schedule） |
| Backlight Compensation |
Off/On (5 Zone) |
| Wide Dynamic Range |
WDR |
| Digital Noise Reduction |
3D DNR |
| Motion Detection |
Off/On (8 Level) |
| Privacy Masking |
Off/On (4 Zone, Rectangle) |
| Gain Control |
Auto |
| White Balance |
Auto/Manual |
| Electronic Shutter Speed |
1/5 ~ 1/20000s |
| Mirror |
Flip/Rotation |
| On-Board Storage |
Micro SD slot, up to 256GB |
| Alarm |
1 input, 1 output |
| Audio |
1 input (RCA), 1 output (RCA |
| Hardware Reset |
Yes |
| Video Compression Format |
H.265/H.264 |
| Resolution |
Main Stream: &30fps1080P(1920x1080) Sub Steam &20fpsVGA(640x480) |
| Video Quality Adjustment |
256Kbps ~ 4Mbps |
| Bitrate control method |
CBR/VBR |
| IP |
IPv6 |
| Streaming Capability |
Dual-Stream (Main/Sub) |
| Protocol |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP |
| Web browser |
IE10/11 |
| Security |
IP address filter; complicated password; Authenticated username and password |
| Streaming Method |
Unicast/Multicast |
| Application Programming Interface |
ONVIF |
| Operating Conditions |
-35～+60°C/less than ≤ 95% RH |
| Ingress Protection |
IP67 |
| Input Voltage / Current |
D12V/POE(IEEE802.3af) |
| Power Consumption （IR OFF） |
2.5W-3.5W |
| Power Consumption （IR ON） |
6.5W-8.5W |
| Material |
Metal |
| Dimensions (H x W x D) |
242*87.4*83.88mm |
| Weight |
811g |
